Introduction:

Ring Hoop Test Machine designed for performed Hope tensile strength tests on pipe samples according to all major international standards. Ring Hoop Test Machine able to perform the test on pipe sample parts in all diameter. This is one of the most important Quality control Test for all diameter.

Process Explanation:

The pipe sample is rolling on supports to be enter on test Machine. it is inserting between plates. and Test procedure starting to determine Hope tensile strength of pipe sample.

Every testing result consist of time and Force detail, date of testing, sample details, series and result of test will be archive on machine with exportable format.

Feature:

Ring Hoop Test Machine is PLC base fully automated machine. The testing can be easily adjust and check on the Control panel and measurement equipment, which is also part of the machine.

Area requirements:

Ring Hoop Test machine Width = 3.00/4.50 meter
Ring Hoop Test machine Length = 3.00/4.50 meter
Ring Hoop Test machine Height = 1.5 meter

Utilities requirements:

Maximum Power Consumption = 10 kW
Maximum Compressed Air Consumption = not require

Operators requirement

One person as supervision for all Test Equipment
One person as machine captain per shift
