Pipe Rectification Machine


Pipe rectification Machine designed for cut the branch of pipe to smaller length for different purpose Like fitting production or  Repair Project. the new small part head will be grinding if require too. Pipe rectification machine able to cutting and Grinding pipe branch between 1 up to 12 meter length.

Process Explanation:

The pipe branch come to Pipe Rectification Machine. It's supporting by the support wheels which are driven by the gear box.

Grooving motor, belt system and grooving tool set are mounted on a hinged support plate which connected to the hydraulic cylinder. This system start to grinding the Pipe cutting side for correcting outside of pipe on this position for sleeve coupling joint.

When grinding is finished, pipe cutting operation starts, while the pipe is still rotating. After procedure finished pipe supports release the pipes.


Pipe rectification Machine Powered by  control box which make the procedure automatic. also it using the laser measuring system which causing precise cutting. in addition smart protection added to prevent any fault during cutting and grinding process.

Optional Add-on:

Due to grinding and cutting operations, dust is a side product. Dust Suction System or Wate Screen System can be added on machine according to customer requirement.

Area requirements:

Pipe rectification machine Width = 3 meter
Pipe rectification machine Length = 14 meter
Pipe rectification machine Height = 3 meter

Utilities requirements:

Maximum Power Consumption = 30 kW
Maximum Compressed Air Consumption = 6 bar, 1.5 m3/min

Operators requirement

One person as supervision for all Line Auxiliary Equipment
One person as machine captain per shift
One person as machine operator per shift
